Engineers at the University of California San Diego have developed a smartphone attachment that could enable people to screen for a variety of neurological conditions, such as Alzheimer’s disease and traumatic brain injury, at low cost—and do so accurately regardless of their skin tone.
The technology was published in Scientific Reports.
The attachment fits over a smartphone’s camera and improves its ability to capture clear video recordings and measurements of the pupil, which is the dark center of the eye. Recent research has shown that tracking pupil size changes during certain tasks can provide valuable insight into an individual’s neurological functions. For example, the pupil tends to dilate during complex cognitive tasks or in response to unexpected stimuli.
However, tracking pupil size can be difficult in individuals with dark eye colors, such as those with darker skin tones, because conventional color cameras struggle to distinguish the pupil from the surrounding dark iris.
To enhance the visibility of the pupil, UC San Diego engineers equipped their smartphone attachment with a specialized filter that selectively permits a certain range of light into the camera. That range is called far-red light—the extreme red end of the visible spectrum located just before infrared light. Melanin, the dark pigment in the iris, absorbs most visible wavelengths of light but reflects longer wavelengths, including far-red light. By imaging the eye with far-red light while blocking out other wavelengths, the iris appears significantly lighter, making it easier to see the pupil with a regular camera.
Another feature of this technology that makes it more accessible is that it is designed to work on all smartphones. Traditionally, pupil measurements have been performed using infrared cameras, which are only available in high-end smartphone models. Since regular cameras cannot detect infrared light, this traditional approach limits accessibility to those who can afford more expensive smartphones. By using far-red light, which is still part of the visible spectrum and can be captured by regular smartphone cameras, this technology levels the playing field.
To use the attachment, a person clips it over a smartphone’s camera and places it over their eye. Then, the smartphone administers a pupil response test by providing a flash of bright light and recording video of the eye during the test. A machine learning model uses the recorded video of the eye to track pupil size.
The researchers tested their smartphone attachment on a diverse group of 12 volunteers with a wide range of eye colors, from light blue to dark brown. The smartphone measurements were validated against a pupillometer, the gold standard device used in the clinic for measuring pupil size.
