Biosensor barcodes identify, detail ‘chatting’ among cancer cells

Dec. 29, 2021

Ever since the first barcode appeared on a pack of chewing gum in 1974, the now-ubiquitous system has enabled manufacturers, retailers and consumers to quickly and effectively identify, characterize, locate and track products and materials.

 In a paper in the journal Cell, researchers demonstrate how they can do the same thing at the molecular level, studying the ways cancer cells “talk” with one another using a different kind of barcode system — one made up of combinations of patterns and colors, with each set tied to a specific biochemical activity in the communication network, according to a news release from Johns Hopkins Medicine.

“When cancer cells communicate, numerous proteins constantly change how they interact with one another,” says senior study author Chuan-Hsiang (Bear) Huang, MD, PhD, Assistant Professor of Pathology at the Johns Hopkins University School of Medicine. “Studying this signaling in depth and in real time has traditionally been difficult, so we needed a method that could simultaneously image, track and analyze everything happening in the network, and therefore, reveal the true relationships among these activities.”

Genetically encoded fluorescent biosensors were previously used to study cellular protein functions, including signaling activities in cancer cells, says Huang. The biosensors are protein fragments tagged with fluorophores — fluorescent molecules that glow by absorbing light energy of a specific wavelength and then emitting light at a longer wavelength — and each color is linked to a specific activity in the cell. Using a fluorescent microscope to image the type, location and intensity of the colors exhibited by these sensors, researchers can accurately and precisely document proteins in action in different cell regions.

“For example, changes in the intensity of specific colors, their locations within cells and the ratio of one color to another shed light on the activity levels of the proteins being studied and how they interact with one another in real time,” says Huang.

However, Huang says the usefulness of fluorescent biosensors was limited when researchers needed to track a complex system like a cancer cell communications network. This, he explains, was because different biosensors often had very similar colors and could not be distinguished from one another when imaged together.

Huang and his colleagues overcame these problems by combining fluorescent proteins of different colors and localization patterns to create “biosensor barcodes,” tools that can concurrently identify and track a larger number of biosensors for various proteins, including those driving cancer formation.

“To track multiple signaling protein activities in parallel, we pair our different biosensors with specific barcodes in individual cells, and then mix and image them using time-lapse microscopy,” says Huang. “Since each cell has a different barcode, we also can use this method to identify different populations of cells in the mix and investigate how they communicate with one another.”

Huang says the images are analyzed with a machine learning system created by study co-author Wei-Yu Chi, MD, Postdoctoral Fellow in his laboratory.
